VOLTA Battery Lithium Ion 7.5KWH 51.2V 150AH

(Volta-Stage-2)

Volta Stage 2 Battery Key Features:

• Two Mounting Methods:
  1. Wall Mounted: Includes a wall bracket for easy installation.
  2. Floor Standing: Comes with a detachable floor bracket for flexible placement.
• High Cycle Life: 6000 cycles at 80% Depth of Discharge (DoD), ensuring long-lasting performance.
• Charge and Discharge: Supports 1C/1C continuous charge and discharge rates.
• Warranty: 5-year standard warranty for peace of mind.
• Safety: Superior LiFePO4 safety performance and low voltage safety connection.
• Scalability: Supports up to 8 modules in parallel for greater capacity.
• Inverter Compatibility: The VOLTA battery BMS supports simultaneous communication and is compatible with multiple inverter brands, providing flexibility and ease of integration into your existing system.

Volta Stage 2 Battery Technical Specifications:

• Product Model: VOLTA STAGE 2
• Nominal Energy: 7.5KWh
• Nominal Voltage: 51.2V
• Nominal Capacity: 150Ah
• Cell Type: Lithium Iron Phosphate (LiFePO4)
• Standard Charge Voltage: 56V
• Max Discharge Current: 150A
• Discharge Cut-Off Voltage: 44.8V
• Parallels Function: Supports up to 8 units in parallel
• Communication Interface: RS485, RS232, CAN (optional)
• Cycle Life: ≥6000 cycles at 80% DoD
• Charge Temperature Range: 0°C to 65°C
• Discharge Temperature Range: -20°C to 65°C
• Certification: MSDS / UN38.3
• Dimensions: 480 x 650 x 180mm
• Weight: 85kg
